Terraces pluvial drain – Gargola

Drawing labels, details, and other text information extracted from the CAD file (Translated from Galician):

No detail, Register for Albanian, Records, Walls, Wall of common partition, No detail, Specifications notes, Iron gargoyel made with plate, Of thickness with hand of, Anti-corrosive paint hands, Enamel paint brand sherwin., Cane Cane Finished, With polished cement cm, Plaque with a hand of, Anti-corrosive paint hands, Enamel paint mark, Sherwin williams blue color, Screw, Expansive tag, Locker of reinforced concrete, Slab of reinforced concrete, Cms., Apparent finish, Side view gargoyle, The gargoyle as an ancient element within the, It is still used in our days by, Its pluvial drainage function of rooftops in a way, Simple functional, Gargoyles can be from de, Of lead from de, Of good types of iron type, Channel angles, An overwhelming look to take care of the installation of, Gargoyles is the sealing of the union between, Roof facade, No detail, Iron gargoyle, Records

Raw text data extracted from CAD file:

5 10 40 2.5 2.5 12 5.1. DETALLE No. REGISTRO PARA ALBANAL 5. REGISTROS ~ 1. MUROS MURO DE TABIQUE COMUN DETALLE No. 1.1. \A1;5 \A1;10 \A1;40 \A1;2.5 \A1;2.5 \A1;12 NOTAS DE ESPECIFICACIONES GARGOLA DE FIERRO HECHA CON PLACA DE 1/4" DE ESPESOR CON 1 MANO DE PINTURA ANTICORROSIVA Y 2 MANOS DE PINTURA DE ESMALTE MARCA SHERWIN. CANALON DE 1/2 CANA ACABADO CON CEMENTO PULIDO R= 2.5 cm PLACA DE 1/4" CON UNA MANO DE PINTURA ANTICORROSIVA Y 2 MANOS DE PINTURA DE ESMALTE MARCA SHERWIN WILLIAMS COLOR AZUL. TORNILLO TAQUETE EXPANSIVO TRABE DE CONCRETO ARMADO LOSA DE CONCRETO ARMADO f'c= 250 kgs/cm2 DE 12 cms. ACABADO APARENTE. 5 10 40 2.5 2.5 12 GARGOLA VISTA LATERAL LA GARGOLA COMO ELEMENTO ANTIGUO DENTRO DE LA CONSTRUCCION, SIGUE SIENDO USADO EN NUESTROS DIAS POR SU FUNCION DE DESAGUE PLUVIAL DE AZOTEAS DE UNA FORMA SENCILLA Y FUNCIONAL. LAS GARGOLAS PUEDEN SER DE BARRO, DE TUBO, DE LAMINA, DE PLOMO O FIERRO, DE ASBESTO/CEMENTO, DE PVC, DE PIEDRA, DE CONCRETO, O BIEN DE PERFILES DE FIERRO TIPO ANGULOS O CANAL. UN ASPECTO IMPPORTANTE A CUIDAR EN LA INSTALACION DE GARGOLAS ES LA FIJACION Y EL SELLADO DE LA UNION ENTRE TECHO Y FACHADA. 5.7. DETALLE No. GARGOLA DE FIERRO 5. REGISTROS

Language	N/A
Drawing Type	Block
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features	Car Parking Lot
Tags	autocad, barn, block, cover, dach, drain, DWG, hangar, lagerschuppen, pluvial, roof, shed, structure, terraces, terrasse, toit
