Rail Detail DWG Section for AutoCAD

Rail Detail DWG Section for AutoCAD

Metallic rail detail with glass and wooden ribbons in plant – Section and view with specifications

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

spout, detail rail floor high, cut, view, plant, scale, spout, ironing board, Wood Ribbons, piece of wood, beam, interior floor, glass, flat front view, Separation between liston liston, scale, ml approximately

Raw text data extracted from CAD file:

CAÑO O 0,10cm \A1;0,2 \A1;0,6 \A1;0,1 \A1;0,4 \A1;0,1 \A1;0,8 \A1;1,3 \A1;1,3 \A1;0,1 \A1;0,1 \A1;0,14 DETALLE BARANDA PLANTA ALTA 5 5 5 5 5 5 5 5 0,1 0,1 5 CORTE VISTA PLANTA ESCALA 1:25 CAÑO 50*30 PLANCHUELA LISTONES DE MADERA 2" X 1" TACO DE MADERA 1" VIGA piso interior VIDRIO VISTA FRONTAL PLANCHUELA separacion entre liston y liston 2" ESCALA 1:25 66 ml aproximadamente

Language	Spanish
Drawing Type	Section
Category	Stairways
Additional Screenshots
File Type	dwg
Materials	Glass, Wood
Measurement Units
Footprint Area
Building Features
Tags	autocad, degrau, DETAIL, DWG, échelle, escada, escalier, étape, glass, ladder, leiter, metallic, plant, rail, section, specifications, staircase, stairway, step, stufen, treppe, treppen, View, wooden
