P+2 residential building plans for an RCC framed structure featuring ground floor parking and two residential levels. Floor plans specify 6″ thk external and 5″ thk internal brick masonry walls with sand-faced and neeru finished plaster. Frst floor layout covers 906 sq. ft. with living (15’6″x18’9″), kitchen (18’6″x9’6″), and bedrooms. Second floor follows a similar footprint with additional bedrooms and balcony spaces. Set includes front elevation, cross-section A-A, and full schedules for doors (MD, D2, D4), windows (W, W1, W2), and ventilators. Material specs list Spartek tile flooring, glazed tiles for WC/Bath, and aluminum sliding windows with MS grills. Foundation is designed for hard strata with specific notes on sink pipe routing through walls. Area statements and site layouts for the water tank and septic tank are included.
