Siege Of Work DWG Block for AutoCAD

Siege Of Work DWG Block for AutoCAD

Provisional installation urbane work

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Fencing of works protection, module, Specifications, Cant, weight, Kg., per unit, Panel made of thick veneer use three panels in recessed between adjacent paramos., Thick sheet metal panel use two panels in recessed between the adjacent paramos., Gate of two of useful width constructed in trapezoidal plate with the corresponding lateral parantes to embed. Includes locking device pins., Intermediate section chamber made of galvanized steel. Fixed to the floor by recess., Kg., Door of a useful width constructed in trapezoidal folded plate of thickness with the corresponding lateral parantes to embed. Includes padlock device., Finish: prepainted yellow, E.m., L.m., Esc., Income of persons, Vehicle entrance

Raw text data extracted from CAD file:

\A1;2.50 \A1;3.64 \A1;2.00 \A1;2.00 \A1;3.00 \A1;3.00 \A1;2.50 \A1;3.00 \A1;0.80 \A1;2.50 \A1;0.84 \A1;3.00 \A1;0.84 \A1;2.00 \A1;3.64 \A1;3.00 \A1;2.00 \A1;9.42 Cerco de proteccion de obra Módulo Especificaciones Cant. Peso 3 10 kg. 9 por unidad Panel de 840mm x3000mm x 29mm, construido en chapa T 101 trapezoidal, espesor 0,4mm.Se utilizan tres paneles en altura, encastrados entre los parantes adyacentes. Panel de 110mm x2000mm x 29mm,construido en chapa T 101 trapezoidal, espesor 0,4mm.Se utilizan dos paneles en altura, encastrados entre los parantes adyacentes. Portón de dos hojas, de 3,48m de ancho útil construido en chapa trapezoidal T 101, con los correspondientes parantes laterales para empotrar. Incluye pasadores y dispositivo para candado. 1 3 Parante intermedio de sección "doble C" de 60mm x40mm x 3000mm, construido en acero galvanizado.Se fija al piso por empotramiento. 6,8 kg. 12 kg. Puerta de una hoja, de 0,80m de ancho útil construido en chapa plegada trapezoidal T 101, de 0,4mm de espesor con los correspondientes parantes laterales para empotrar. Incluye dispositivo para candado. Acabado: prepintado color amarillo 1 5 3.64 5 5 5 5 5 5 5 5 5 5 E.M. E.M. L.M. 5 5 5 \A1;0.80 5 5 Esc. 1:100 Ingreso de personas Ingreso de vehiculos 5
