This drawing depicts the structural layout and construction details of a tiered bleacher system for a stadium or sports venue. The plan shows a rectangular arrangement with a 5-column grid structure spanning approximately 5.25m between columns (shown as axes 1-5), with three rows designated by axes A-C. The sections reveal a stepped profile with detailed and thorough dimensions for riser heights and tread depths. The bleacher structure includes different configurations along various grid lines, with specific details shown for standard sections and the sections along structural beam axes. Each section displays the proper slope for spectator sightlines with approximately 4.3m total height. The drawing includes both plan and sectional views at 1:25 and 1:50 scales respectively, allowing for comprehensive understanding of the structural system. Careful attention has been given to the dimensional coordination between structural grid and seating layout, ensuring proper load distribution across the supporting elements.
Stadium bleacher System Plan and Sections with Structural Grid
