Thickener sludge PLANT AND SECTION

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Bench for control head, Tensors, cover, Bottom scrapers, Floor without cover, section, Bench for control head, rotor, railing, Polyester cover, Baffle, Drainage well, Lateral scraper, reinforced concrete, Tensors, Dump plates, Sludge dehydrator, Mm, Scraper to concentrator, cleaning concrete, Tensors, Neoprene band, detail, detail, scale

Raw text data extracted from CAD file:

\A1;2.9951 \A1;2.50 \A1;\U+22056.7000 \A1;\U+22057.2500 \A1;0.2500 \A1;0.2500 \A1;0.0500 \A1;0.1500 \A1;0.3000 \A1;0.4000 \A1;0.1500 BANCADA PARA CABEZA DE MANDO TENSORES CUBIERTA RASQUETAS DE FONDO PLANTA SIN CUBIERTA SECCIÓN BANCADA PARA CABEZA DE MANDO ROTOR BARANDILLA BARANDILLA BARANDILLA CUBIERTA DE POLIESTER CAMPANA DEFLECTORA A POZO DE DRENAJES RASQUETA LATERAL HORMIGÓN ARMADO HA-35 TENSORES CHAPAS VERTEDERO A DESHIDRATADOR DE FANGOS DN 150 mm RASQUETA AL CONCENTRADOR HORMIGÓN DE LIMPIEZA TENSORES 5 2.50 5 5 BANDA DE NEOPRENO BANDA DE NEOPRENO 5 5 5 DETALLE 1 5 ALZADO-SECCIÓN 5 5 5 DETALLE 1 ESCALA 1/25
