This drawing is for a screw reducer assembly featuring the helical gear and worm screw components. We’ve included section views (Corte A-A & B-B) along with full technical tables for module size, tooth count, and axis spacing. Dimensions are in mm with specific material notes for 18 CN 16 UNI 2953. This could be useful in mechanical assembly design and industrial gearbox projects.
Worm Gear and Screw Reducer Section Details Drawing
