A comprehensive 3-story townhouse (LK03-01) construction drawing set with complete architectural, structural, and MEP details. The building features 93.3m² on the first floor, 118.4m² on the second floor, and 101.9m² on the third floor.
Architectural Components:
– First floor: Commercial space, kitchen/dining area, and living room
– Second floor: Five bedrooms with bathroom facilities
– Third floor: Additional bedrooms, prayer room, and drying terrace
– Xingfa aluminum door and window systems with 6.38mm and 8.38mm safety glass
Structural Details:
– Reinforced concrete frame construction with 10cm thick concrete slabs
– Detailed beam sections (220x300mm to 300x400mm) with reinforcement specifications
– Foundation and structural grid system with column layout
– 10A200 rebar specifications for floor reinforcement
MEP Systems:
– Complete electrical layout with lighting, switches, and outlet positions
– Water supply system with 2m³ rooftop water tank
– PPR hot and cold water piping network
– Bathroom fixture layouts including toilets, sinks, and showers
All drawings provided at 1:75 scale with comprehensive material specifications, construction details, and finishing schedules.
