Access Stair DWG Block for AutoCAD

Access steel stair

Drawing labels, details, and other text information extracted from the CAD file:

title, see plans for dimension, min., eq., plans for dimension, dia. pipe, weld to stringer, handrail supports, max. between, exp. bolts, attach to floor, stl. channel, support brackets, checker plate, wide, eq., eq., min., max., see plans for dimension, tread, stringer

Raw text data extracted from CAD file:

A TITLE 0 3″ 6″ 1′ SEE PLANS FOR DIMENSION MIN. EQ. EQ. 900 178 50 900 \A1;EQ. \A1;178 \A1;EQ. \A1;50 \A1;MIN. \A1;SEE PLANS FOR DIMENSION \A1;900 \A1;900 31 DIA. PIPE RAIL, WELD TO STRINGER 30° TO 50° HANDRAIL SUPPORTS 1200 MAX. BETWEEN W/ EXP. BOLTS ATTACH TO FLOOR STL. CHANNEL SUPPORT BRACKETS CHECKER PLATE 6X900 WIDE EQ. 178 EQ. 5 MIN. 150 300 MAX. SEE PLANS FOR DIMENSION TREAD STRINGER 5 5
