This floor plan details the 27th floor refuge layout for Block J of a high-rise residential tower. The design features multiple unit configurations including 2BHK (Type 01, 02, 03) and 3BHK (Type D1, D2, D3, D4) apartments arranged around a central core. The refuge floor incorporates emergency egress routes with clearly marked stairwells on opposite sides of the building, ensuring code-compliant evacuation paths. Each apartment unit includes detailed interior layouts with furniture placement, bathroom fixtures, and kitchen appliances. The central corridor provides access to all units with approximately 1500mm width for emergency accessibility. Notable design features include strategic placement of service shafts, structural columns integrated within partition walls to maximize usable floor area, and sliding door configurations in living areas to enhance spatial flexibility. The plan effectively balances density requirements while maintaining adequate circulation and safety standards for a refuge floor in a multi-story residential development.
Block J 27th Floor Refuge Plan with 2BHK & 3BHK Unit Layouts
