Connection double walls of blocks of cement with metallic pillar

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Detail with block seen in joint of pillars, Pillar metal pillar, Block seen, Supalux mm

Raw text data extracted from CAD file:

\A1;300 \A1;40 \A1;300 DETALLE CON BLOQUE VISTO 40X20X20 EN JUNTA DE PILARES 5 PILAR METALICO TPO “HEA-220 / 200” BLOQUE VISTO 40X20X20 5 5 SUPALUX e=20 mm
