Curtain Wall DWG Block for AutoCAD

Curtain Wall DWG Block for AutoCAD

Curtain Wall – Unit-and-mullion system

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

double glazing with leaves, different dimension, metal piece union tubular elements., steel profile, profile union structure facade, with greater structure, special piece union elements, diagonal the structure of, facade., will be welded to the tubular profile of, Steel angle anchor., structural silicone, profile cortaon type luxalon aerobrise, lattice structure steel profile, collaborating slab, natural terrain, Water, compacted terrain, slate stone siding, gravel cms, duct space water system, underwater lighting beacon, compacted sand, h.r., reinforced concrete foundation slab, slab floating pool lounge, events, tubular profile, vertical structure, facade of, concrete chicken, structure, stainless steel anchor, special design, Special piece for column union, metal with concrete foundation, exterior cladding type luxalon tile, steel tubular profile, horizontal structure, facade of, piece of special rubber, planar system union with cladding, Exterior, mdf board floating floor, union in structural silicone, double glazing., external blade type: pilkington optifloat, special green in pieces, that incorporate, inner sheet type: optifloat clear, glass facade

Raw text data extracted from CAD file:

1,00 40 8 7 12 2,00 50 18 88 55 27 1,15 88 95 Doble cristal con hojas de diferente dimensión Pieza metálica unión elementos tubulares. perfil acero 100x100mm Perfil unión estructura fachada con estructura mayor 100mm Pieza especial unión elementos diagonales a la estructura de fachada. Se soldará al perfil tubular de 150mm anclaje acero inoxidable, ángulo. Silicona estructural Perfil cortason tipo Luxalon Aerobrise 200 Estructura celosía perfil acero 50x50mm (verticales y horizontales) Losa colaborante 15cms Terreno natural Agua Terreno compactado 20cm Revestimiento Piedra Pizarra Ripio 15 cms Espacio para ductos y sistema de agua Faro de iluminación subacuática arena compactada H.R. 80% Losa de Fundación hormigón armado Losa flotante piscina salón de eventos Perfil tubular 150mm (elemento vertical estructura fachada de cristal) Pollo de Hormigón (llegada estructura metálica) Anclaje acero inoxidable diseño especial Pieza especial para unión de columna metálica con fundación Hormigón revestimiento exterior tipo Luxalon Tile Perfil tubular acero 100mm (elemento horizontal estructura fachada de cristal) Pieza de goma especial Unión Sistema Planar con revestimiento exterior Tablero de mdf 25mm. Piso flotante Unión en silicona estructural 8mm Azcristalamiento doble. Hoja externa tipo: Pilkington Optifloat green 10mm (cerigrafiado especial en piezas que incorporan CASINO) Hoja interna tipo: Optifloat Clear 10mm D3 D2 ESCANTILLÓN FACHADA DE CRISTAL 1:10

Language	Spanish
Drawing Type	Block
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Glass, Steel
Measurement Units
Footprint Area
Building Features	Pool
Tags	aluminio, aluminium, aluminum, autocad, block, curtain, DWG, gesso, gips, glas, glass, l'aluminium, le verre, mauer, mur, panels, parede, partition wall, plaster, plâtre, system, vidro, wall
