Detail Cable Hanger Under Ground DWG Section for AutoCAD

Detail Cable Hanger Under Ground DWG Section for AutoCAD

Details cable hanger under ground – Lateral section

Drawing labels, details, and other text information extracted from the CAD file (Translated from Italian):

data transport channel, main channel, direct piping to the picture, side section, flexible, plastic tube, self-extinguishing, quick coupling, presser foot nozzle, pav. floating

Raw text data extracted from CAD file:

CANALE TRASPORTO DATI CANALE PRINCIPALE TUBAZIONE DIRETTA AL QUADRO SEZIONE LATERALE FLESSIBILE TUBO PLASTICA AUTOESTINGUENTE A INNESTO RAPIDO BOCCHETTONE PRESSATUBO PAV. GALLEGGIANTE
