ARE PRESENTED IN THIS OPPORTUNITY THE DETAILS NEEDED FOR A GOOD PRESENTATION OF ELECTRICAL INSTALLATIONS PLANNING .

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Kwh, Pipe for timbre, Connection pipe, Switching switch, Phone out, General distribution board, Pipe roof, Pipe by floor wall, Tv cable outlet, measurer, variable, High power outlet, Double simple outlet, Spot light, Center of light, Bracket, Double switch, Simple switch, variable, Legend of electrical installation, description, symbol, Rect., special, Cuad., Rect., Cuad., Rect., oct., Rect., oct., box, height, Exit for therma, variable, special, Telephone line, variable, Pipe for tvc, variable, intercom, variable, intercom, variable, Npt., Npt., Npt., floor, floor, rush, Ntt., rooftop, Detail of exits, in kitchen, Power outlets, In bathrooms, Boards, N.p.t., kitchen, Outlet, TV. phone, Power outlets, switch, Technical specifications, All conductors will be electrolytic copper conductivity. Will have insulation of pvc of the type thermoplastic the minimum conductor to use will be of section. All pipelines will be made of polycarbonate of all outlets that reach more than three conductors will use a rectangular outlet box of mm. All output boxes will be heavy duty galvanized iron. The distribution board will be embedded with galvanized iron thermomagnetic switches will be used with the amperage indicated in the single line diagram, In pvc sel, Floor lighting, floor, Tw in pvc sel, In pvc sel, Floor lighting, Floor outlets, Tw in pvc sel, In pvc sel, Floor lighting, Floor outlets, Tw in pvc sel, reservation, measurer, Line, Groundwater well cu pvc sap, In pvc sel, Floor lighting, Floor outlets, Tw in pvc sel, Nm., Tw in pvc sel, Kitchen floor, reservation, reservation, reservation, Therma floor, Tw in pvc sel, For lighting, Aligners, Circuit of outlets, Of location of the t.d., Copper rod, Compacted sieving, farmland, Mixed with kg., In pvc sap, Copper connector, Bare copper cable, naked, Copper wire, Grounding, The grounding system will be constituted by a cable laying well that will not have direct contact with it for what should be in pipe pvc sap ø., Torch lamp, wall, Torch type bracelet, Fixed with plastic stud bolt, Decorative halogen lamp, Electrical conduit, Heaven’s reason, Detail spot installation, Of partition, Wall, N.p.t., Galv sheet registration box., Duplex contact, Duplex contact cover, Double outlet, Tw mm, key, description, Tw mm, Diameters, Equivalents in ducts, Driver colors, L. driver, color, Live line, Neutral line, Earth line, Red, White, yellow

Raw text data extracted from CAD file:

W-h S S2 KWH \A1;0.30 \A1;0.15 \A1;0.45 \A1;0.60 \A1;0.20 \A1;0.20 \A1;0.30 \A1;0.30 \A1;0.40 \A1;0.54 \A1;1.40 SC TUBERIA PARA TIMBRE TUBERIA PARA ACOMETIDA INTERRUPTOR CONMUTACION SALIDA DE TELEFONO TABLERO GENERAL O DISTRIBUCION TUBERIA POR TECHO O MURO TUBERIA POR PISO O MURO SALIDA DE TV x CABLE MEDIDOR 1.40 0.40 1.40 0.40 1.40 VARIABLE VARIABLE VARIABLE VARIABLE TOMACORRIENTE ELEVADO TOMACORRIENTE SIMPLE / DOBLE SPOT LIGHT CENTRO DE LUZ BRAQUETE 1.20 2.40 0.40 INTERRUPTOR DOBLE INTERRUPTOR SIMPLE 1.40 1.40 VARIABLE VARIABLE LEYENDA DE INSTALACION ELECTRICA DESCRIPCION SIMBOLO Rect. 4"x2" Especial Cuad. 5"x5"x3" Rect. 4"x2" Cuad. 8"x8"x4" Rect. 4"x2" Oct. 4"x4" Rect. 4"x2" Rect. 4"x2" Rect. 4"x2" Oct. 4"x4" Oct. 4"x4" CAJA F°G° ALTURA T V Th SALIDA PARA THERMA VARIABLE Especial TUBERIA PARA TELEFONO VARIABLE TUBERIA PARA TVC VARIABLE INTERCOMUNICADOR VARIABLE INTERCOMUNICADOR VARIABLE M O N T A N T E E L E C T R I C A 150x100mm. TD-2 TD-3 PVC-SEL 1"d PVC-P35mm2 3x16mm2TW 3x16mm2TW TG 200x100mm. NPT. ±0.00m ±0.00m NPT. ±0.00m ±0.00m NPT. NPT. 1 PISO 2 PISO 4TO PISO 1 3 PISO 100x50mm. PVC-P35mm2 3x16mm2TW ACOMETIDA TD-1 100x50mm. NTT. ±0.00m AZOTEA PVC-P35mm2 DETALLE DE SALIDAS en cocina TOMACORRIENTES en baños TABLEROS N.P.T. COCINA TOMACORRIENTE T.V. Y TELEFONO TOMACORRIENTES INTERRUPTOR 0.40 1.40 1.20 0.40 1.20 ESPECIFICACIONES TECNICAS 1º TODOS LOS CONDUCTORES SERÁN DE COBRE ELECTROLITICO DE 99.99% DE CONDUCTIBILIDAD. 2º TENDRAN AISLAMIENTO DE PVC DEL TIPO TERMOPLASTICO (TW). 3º EL MINIMO CONDUCTOR A EMPLEAR SERÁ DE 2.5 mm2 DE SECCIÓN. 4º TODAS LAS TUBERIAS SERÁN DE POLIVILINO ( PVC) DEL (SEL). 5º TODOS LOS TOMACORRIENTES A LOS QUE LLEGUEN MAS DE TRES CONDUCTORES USARÁN UNA CAJA DE SALIDA RECTANGULAR DE 100 x100 mm. 6º TODAS LAS CAJAS DE SALIDA SERÁN DE FIERRO GALVANIZADO DEL TIPO PESADO. 7º EL TABLERO DE DISTRIBUCION SERÁ EMPOTRADO DE FIERRO GALVANIZADO Y SE USARÁN INTERRUPTORES TERMOMAGNÉTICOS CON EL AMPERAJE INDICADO EN EL DIAGRAMA UNIFILAR TD-4 C-1 2x40A 2-1x2.5mm2TW en 01 PVC SEL 20mmd ILUMINACION 1ER PISO 2x15A C-2 C-3 2x30A 2x10mm2 TW+1x10mm2.TW (T) d 25 mm2.PVC-P 2x40A TOMACORRIENTES1ER PISO 2-1x4.00mm2TW +1x 4.0 mm2. TW (T) en 01 PVC SEL 20mmd C-1 2x20A 2-1x2.5mm2TW en 01 PVC SEL 20mmd ILUMINACION 2DO PISO 2x15A C-2 C-3 2x40A TOMACORRIENTES 2DO PISO 2-1x4.00mm2TW +1x 4.0 mm2. TW (T) en 01 PVC SEL 20mmd C-1 2x20A 2-1x2.5mm2TW en 01 PVC SEL 20mmd ILUMINACION 3ER PISO 2x15A C-2 C-3 2x20A 2x40A TOMACORRIENTES 3ER PISO 2-1x4.00mm2TW +1x 4.0 mm2. TW (T) en 01 PVC SEL 20mmd RESERVA MEDIDOR DE LINEA TD - 01 TD - 02 TD - 03 POZO DE PUESTA A TIERRA 1x 10.00 mm2 ø Cu PVC - SAP ø 1" C-1 2x20A 2-1x2.5mm2TW en 01 PVC SEL 20mmd ILUMINACION 4TO PISO 2x15A C-2 C-3 2x40A TOMACORRIENTES 4TO PISO 2-1x4.00mm2TW +1x 4.0 mm2. TW (T) en 01 PVC SEL 20mmd TD - 04 DIAGRAMA UNIFILAR 2-1x4mm2. TW + 1x4mm2 TW(T) en PVC SEL 20mmd COCINA (4,000W.) 1ER PISO C-4 2x30A 2x20A RESERVA 2x20A RESERVA C-3 2x20A RESERVA 2x15A THERMA (1,200W.) 5TO PISO (AZOTEA) 2-1x2.5mm2TW +1x 2.5mm2. TW (T) en 01 PVC SEL 20mmd 0.54 Para Alumbrado Alineadores 25 mm2 PVC-L circuito de tomacorrientes 20 mm2 PVC-L 1.40 \L\ODETALLE DE UBICACION DEL T.D. ESC=S/E DE Ø 3/4" x 2 .50m. VARILLA DE COBRE 0.30 0.15 0.45 CERNIDO Y COMPACTADO TIERRA DE CULTIVO MEZCLADA CON 5 Kg. 1x25mm2 EN PVC SAP d 1" CONECTOR DE COBRE CABLE DE COBRE DESNUDO 0.60 0.20 0.20 0.30 0.30 0.40 DESNUDO 1x25mm2 CABLE DE COBRE \L\ODETALLE DE PUESTA A TIERRA ESC=1:25 El sistema de puesta a tierra estará constituido por un pozo de puesta a tierra, mediante cable de 10mm², el mismo que no deberá tener contacto directo con el terreno, para lo que deberá estar en tuberia PVC SAP 25mm Ø. LAMPARA TIPO ANTORCHA 20 W PARED (S/E) BRAQUETE TIPO ANTORCHA FIJADO CON PERNO Y TARUGO PLASTICO Ø 1/2"x1/2" LUMINARIA DE HALOGENO DECORATIVA CANALIZACION ELECTRICA CIELO RAZO DETALLE INSTALACION DE SPOT (S/E) DE TABIQUE MURO # \A1;40 cm # N.P.T. CAJA REGISTRO DE LAMINA GALV. CONTACTO MONOFASICO, DUPLEX TAPA PARA CONTACTO DUPLEX (S/E) TOMACORRIENTES DOBLE z 2 x 4.00mm2 TW+1X2.5mm2(T) PVC-SEL d 20 mm x w v 3 x 2.50mm2 TW PVC-SEL Ø 20 mm 2 x 2.50mm2 TW PVC-SEL d 20 mm 2 x 10mm2 +1X10mm2 (T) TW PVC-P d 25 mm clave DESCRIPCION y 2 x 4.00mm2 TW PVC-SEL d 20 mm DIAMETROS EQUIVALENTES EN DUCTOS COLORES DE CONDUCTORES d (MM) d (PULG) 20 25 35 3/4" 1" 1 1/4" L. CONDUCTOR COLOR LINEA VIVA LINEA NEUTRA LINEA A TIERRA ROJO BLANCO AMARILLO
