Partition and door arrangement plan for the eleventh floor of a large-scale commercial office project. Includes detailed layouts for huddle rooms, cabins, a 16PAX coach room, phone booths and an open workfloor area. Partition types are specified in the legend, featuring STC 50 drywall (130mm thk.), STC 45 drywall, 2-hour fire-rated drywall, and 200mm AAC block walls. Door schedule covers 2-hour fire-rated glass swing doors (1500×2600 & 1200×2600), metal fire doors, and modular glass partitions. Drawing includes elevator lobby details, service cores (AHU, IDF, storage), and facade mullion callouts. Dimensions are in mm and set out from finish face or column surfaces as noted.
Eleventh Floor Partition and Door Arrangement Plan for Commercial Office
