Interconnection diagram for the Flanders PZ35 ARDVARC system all-stop enclosure, specifically the autonomous drilling configuration for Salobo. Detailed wiring for AB CompactLogix L16ER PLC and 24VDC 5A PS units incl. M12 4-pin A-coded plug-ins. Covers master/aux remote stop circuits, PLC Ethernet, and 120/240VAC 50/60Hz input power routing. Diagrama de interconexão para o sistema Flanders ARDVARC
Flanders ARDVARC All-Stop Enclosure Electrical Interconnection Wiring Diagram
