Connection diagram for the Flanders ARDVARC PZ35 autonomous drilling system, specificaly covering the Remote I/O Module M02. This schematic details the wiring for Node 13/32 including the valve station connections and various digital input/output points. It maps out pin assignments for critical components like the hoist winch, tower controls, and dust blower systems. I’ve included the specific connector tags from J13 through J26 along with wire color codes like BRN, BLK, and BLU for easy reference. The drawing also features a notes table defining cable types such as splitter, crossover, and resistor cables.Standard industrial layout.
Flanders ARDVARC PZ35 Remote I/O Module M02 Connection Diagram
