Foundation Under Wall DWG Section for AutoCAD

Constructive section of subwall construction in masonry in the case of sub pressure

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Median axis, Existing wall, Ceramic floor, Thin layer adhesive, Regularizer folder, Lightweight concrete subfloor, Hc compression layer, Ceramic brick, Prestressed joist, Gypsum ceiling applied, Thickened, Vertical watertight insulation mci, Projected monolayer plaster, brick, demolish, Shoe hrp poor concrete run, Recalculate hc, Waterproof insulation mci, Thickness cm underlayment wall, Waterproof insulation mci, Asphalt insulating membrane, Expanded polystyrene expansion chamber, plinth, Rubber sole, Regularizer folder, Armor of, Slab of sub-pressure, Waterproof insulation mci, Asphalt insulating membrane, Hhrp underfloor, Shoe hrp poor concrete run, Expanded polystyrene expansion chamber, Asphalt felt, adhesive, Leveling mass, Sub-masonry submission for the case of sub-pressure, Ext., Int.

Raw text data extracted from CAD file:

eje medianero pared existente solado ceramico adhesivo de capa delgada carpeta regularizadora contrapiso de hormigon liviano capa de compresion HC 1:3:3 ladrillon ceramico vigueta pretensada cielorraso de yeso aplicado engrosado aislante hidrofugo vertical MCI 1:3 (1 cm) revoque proyectado monocapa ladrillo (25×5.5×12 cm) a demoler zapata corrida de hormigon pobre HHRP 1:1/4\H1.333x;:4:8 recalce HC 1:3:3 aislante hidrofugo MCI 1:3 (2 cm) muro de submuracion (45 cm de espesor nominal) aislante hidrofugo MCI 1:3:3 (1 cm) membrana aislante asfaltica camara de dilatacion poliestireno expandido zocalo solado de goma carpeta regularizadora armadura ( d del 8 mm) losa de subpresion de H°A° (14 cm) aislante hidrofugo MCI 1:3 (1 cm) membrana aislante asfaltica contrapiso HHRP 1:1/4\H1.333x;:4:8 zapata corrida de hormigon pobre HHRP 1:1/4:4:8 camara de expansion poliestireno expandido fieltro asfaltico adhesivo masa niveladora submuracion de mamposteria para el caso de subpresion ext. int.
