This site plan details a gas distribution facility situated on Stand No. 19819, featuring a 30-ton LPG storage installation with 2700mm diameter tanks. The drawing includes detailed, essentially, tank specifications with 14mm shell thickness and 1.77MPa design pressure. A firewall surrounds the tank area (194m²) with specific construction details including anchor bolt configurations and seismic reinforcement. The plan shows building setbacks (3m, 5m, and 10m building lines), existing office structures (127.5m²), and a proposed distribution shed (12m²). The site includes safety features like perimeter fencing with pig wire around the 3700m² total stand area, and dedicated water tanks for fire suppression. Technical specifications include a fire suppression system capable of delivering 783.6 L/min at 3.5 bar with a tank sized for 60 minutes operation (47m³ capacity). The layout accommodates prevailing easterly winds—a critical safety consideration for vapor dispersal in LPG installations.
Gas Station Site Plan with 30-Ton LPG Storage Tank installation
