Campus Master Plan Overview
This comprehensive site plan depicts a multi-building hospital campus with integrated landscaping elements. The drawing includes detailed external circulation patterns, parking facilities, and specialized landscape treatments. The campus features multiple medical buildings including a General Hospital, Women and Children’s Hospital, Morphology Building, and various specialty clinics with clearly marked entrance points.
The site plan demonstrates significant topographical considerations with elevation changes throughout the campus, ranging from +8.50 (48.50) to -21.50 (18.50), with a reference elevation of ±0.00=40.00. Various ramp systems manage these elevation changes, with slopes typically between 5-12% and lengths from 28m to 205m.
Key Circulation Elements:
– Multiple vehicle entrance/exit points including dedicated ambulance access
– 8+ parking areas with approximately 400+ standard spaces plus designated spots for electric vehicles, disabled access, and service vehicles
– Comprehensive pedestrian pathway network with accessible routes
– Bicycle pathways with dedicated parking facilities (20+ spaces)
– Bus stops at strategic campus entry points
Landscaping Components:
– Green roof systems in multiple configurations (walkable and non-walkable)
– Technical specifications for planting including soil depths, drainage, and root barrier systems
– Children’s play areas with specialized equipment
– Various site furnishings including benches, pergolas, gazebos, and lighting
– Slope stabilization systems using high-strength steel mesh
– Gabion retaining walls at multiple locations
The drawing includes detailed construction specifications with reference codes (KGM, BP.ÖBFA, YP.ÖBFA) for landscaping materials, hardscape elements, and furnishings to be implemented throughout the campus.
