Isolated Footing Detail DWG Detail for AutoCAD

Isolated Footing Detail DWG Detail for AutoCAD

Isolated footing Detail

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

main armor, base of hºa, fixation, wire, given of hºaº, expanded polystyrene, of thickness, stirrup, base of hºa, trunk armor, of column, stirrup, bracing beam, stirrup, sector foundation of the s.u.m., scale, scheme of armed a base, scale, of the classroom sector, cut, plant

Raw text data extracted from CAD file:

Armadura principal Base de HºA d 10 c/15 Fijación de alambre Dado de HºAº (raviol) Poliestireno expandido 0,02 m de espesor Estribo d6 c/15 Base de HºA d 8 c/15 Armadura de tronco De columna 4 d 16 Estribo d8 c/20 Viga de arriostramiento 3 d 10 Estribo d6 c/14 FUNDACIÓN SECTOR DEL S.U.M. ESCALA 1:10 ESQUEMA DE ARMADO DE UNA BASE ESCALA 1:10 DEL SECTOR AULAS CORTE PLANTA

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features
Tags	autocad, base, DETAIL, DWG, footing, FOUNDATION, foundations, fundament, isolated
