Main Pulley – Twist Drill DWG Block for AutoCAD

Main Pulley – Twist Drill DWG Block for AutoCAD

Main Pulley – Twist Drill

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

tolerances not indicated, lengths without tolerance, not indicated chamfers, plan number, scale, file, Format, weight, model, machine, surface symbols, modifications, group, drawn, observations, material, cant, description, samuel, position, column drill, main pulley, ribbed hub, marcano

Raw text data extracted from CAD file:

Tolerancias no indicadas H12 / h12 Longitudes sin tolerancia ± 0.25 \A1;8 \A1;60.0° Chaflanes no indicados 1x45 ° d 103,9 d 129 d 158,9 d 184 d 178,9 d 204 d 208,9 d 228 d 234,9 d 254 d 51 40 M 40 X1,25 d 79 9 6 9 6 9 6 9 6 9 9 78 73,5 73,5 147 13 160 R 3 45° 33° 10/10/2012 A3 Nº Plano Escala Fichero Formato Peso (kg) Modelo Tr.termico/superf. MAQUINA 1.6 3.2 12.5 6.3 0.8 0.4 Simbolos de superficie Ra d c b a Modificaciones Grupo Dibujado Observaciones Material Cant. Descripcion Samuel Posicion P01 1:2 P01 Taladro columna 4,5 Kg Polea principal 1 AC.F-155 1 1 Cubo nervado A24X28X8 DIN-5471 A A d<> d<> d<> d<> d<> d<> d<> d<> d<> d<> d<> 1 M<>X1,25 d<> 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 <> 1 1 A-A Marcano
