This technical drawing depicts detailed specifications for a clevis-type mechanical connector in multiple orthographic views. The drawing includes both top views (T.V.) and front views (F.V.) showing the component from different perspectives with precise dimensional information. The connector features a clevis fork design with circular pin holes (approximately 20mm diameter) and connecting elements with varying thicknesses. Key dimensions include a total length of approximately 125mm, width of 50mm, and various critical tolerances for proper mating with connecting parts. The drawing shows cross-sectional details revealing internal features and material thickness requirements. The design incorporates rounded transitions and specifically dimensioned clearances to allow proper articulation while maintaining structural integrity. This type of connector is typically used in mechanical linkage systems where pin connections and pivoting movement are required.
Mechanical Clevis Connector Detail Drawing with Top and Front views
