Paving Stone DWG Section for AutoCAD

Paving Stone DWG Section for AutoCAD

Detail about paving stone – Section – Technical specifications

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

minimum, Pending at the end of the, natural terrain, Cemented with a thickness of, Improved base of tepetate gravel, In proportion with a thickness, Mortar of, Basaltin color according to sample, Artificial oil tank of, Approved

Raw text data extracted from CAD file:

\A1;1.00 \A1;10cm.± \A1;2.00 \A1;1.60 5 SUB-BASE 1.5% MINIMO PENDIENTE EN LA TERMINACION DE LA TERRENO NATURAL 10cm.± CEMENTADA CON UN ESPESOR DE 10cm. BASE MEJORADA DE TEPETATE O GRAVA EN PROPORCION 1:5 CON UN ESPESOR MORTERO DE CEMENTO-ARENA BASALTIN O SIMILAR, COLOR SEGUN MUESTRA ADOQUIN PETREO ARTIFICIAL DE 10x10x8cms. 5 DE 5cm. APROBADA 5

Language	Spanish
Drawing Type	Section
Category	Construction Details & Systems
