Portable Toilet DWG Block for AutoCAD

Portable Toilet DWG Block for AutoCAD

Portable toilets designed for the mountain

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Yes it is, Mosquito net, scale:, The calamine the wood will be painted. Warm areas we recommend a color, The trench will be used until below the level of the one after which it will be filled the house will be moved, In case of zones with winds very thrusters will be used to assure the calamines, The opening of the gate of the house must be located perpendicular to the predominant direction of the wind, The splicing between the base of the house with the trunks that serves as brocal will be made through wire #, cut, belt, Mosquito net, Armella, Rubber stopper, Hinge, lead, string, Galvanized calamines, Hinge, Galvanized calamine, Of the calamine, Junction area, Mosquito net, Galvanized calamines, Armella, Lead similar, Galvanized calamine, air duct, plant, Roof projection, Projection mechanism, handle, Automatic closing, Crockery detail, Thin rubbed finish, cut, Union between the slabs, Minimum coating treated wood type, Specifications, cut, The edge of the latrine must be at least compact ground other material, In case of land the walls of the pit reinforced with materials of the zone that can be: stones etc., In any case, space must be left for percolation., The trunks used as a broach will be joined down so that they form a square, Compact, Earth

Raw text data extracted from CAD file:

SI ES 1/200 A3 Malla mosquitero 2,00 1,00 0,15 0.30 0.45 0,25 2.60 2,00 0,20 0.36 0.40 2,00 1,00 0.45 0,70 2,20 0.45 0.45 0.15 0,25 0.15 0,05 0,90 0,05 0,79 0,10 0,10 0,33 0,10 0,30 0,03 0,31 0,21 0,35 0,05 1,00 0,05 0,07 1/20 ESCALA: 5 9. La calamina y la madera se pintaran. (en zonas calidas se recomienda un color claro) 8. El foso se usara hasta 50cm por debajo del nivel del terreno, luego de la cual se rellenara y se trasladara la caseta 7. En caso de zonas con vientos muy fuerte, se usaran tirafones para asegurar las calaminas 6. La apertura de la puerta de la caseta se debe ubicar perpendicular a la direccion predominante del viento 5. El empalme entre la base de la caseta con los troncos que sirve de brocal se hara a traves de alambre Nº 8 5 Corte B-B 0.30 0.45 5 5 2" X 4" 1" x 3" Correa 1" x 2" Malla mosquitero Armella 1/2" 3/4" x 3/4" x 2" Tope de maera y caucho d 6" 2 " x 2" Bisagra de 3" Plomo Cordel 1" x 2" 2 Calaminas galvanizadas de 1.83 x 0.83 x 0.0025 m 2.60 5 5 Bisagra de 3" 0.36 0.40 Calamina galvanizada 2.44 x 0.83 x 0.0025 m de la calamina Zona de empalme Malla mosquitero 2 Calaminas galvanizadas de 1.83 x 0.83 x 0.0025 m Armella 1/2" Plomo o similar 2.44 x 0.83 x 0.0025 m Calamina galvanizada Tubo de ventilacion d 4" 5 5 0.45 5 5 0.45 0.45 0.15 Planta 5 A 0.15 5 5 5 B 5 A B Proyeccion de techo Proyeccion de mecanismo de Manija cierre automatico 5 5 2 1 5 5 5 5 5 5 5 Detalle de Loza 2 1 5 5 5 Acabado frotachado fino d 3/8" @ .20 d 3/8" @ .25 R= 4cm R= 9cm 5 Corte 2-2 Corte 1-1 Union entre las losas 7.5 cm R =1cm R =3cm Recubrimiento minimo 1" madera tipo c tratada f 'c = 175 kg/cm2 fy = 4200 kg/cm2 ESPECIFICACIONES Corte A-A 3. El reborde de la letrina debe sobresalir por lo menos 15cm y sera de tierra compacta u otro material 1. En caso de terrenos flojos, las paredes del foso se reforzaran con materiales de la zona que pueden ser: troncos, piedras etc. 2. En cualquiera de los casos se debe dejar espacio para la percolacion. 4. Los troncos usados como brocal se uniran rebajados de tal manera que formen un cuadrado COMPACTA TERRAPLEN TIERRA 3"x1" 3" x 1" 3" x 1"
