Residencial Housing 2 Plants DWG Section for AutoCAD

Residencial housing two plants – Plants- Sections – Views

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

stay, graphic scale, assembly plant, ground floor, upper floor, north elevation, west elevation, section a-a ‘, section b-b’

Raw text data extracted from CAD file:

ESTANCIA 24,2 28,3 24,2 28,3 0.50 3.00 2.00 1.00 0.00 1.50 4.00 5.00 10.00 mts. ESCALA GRAFICA A A´ B’ B 5 5 5 5 Planta de Conjunto Planta Baja A A’ B’ B 1 2 3 4 5 6 7 8 9 10 11 12 13 Planta Alta B’ B A A’ 14 15 16 17 7 Alzado Norte Alzado Poniente Sección A-A’ Sección B-B’ 1 Recibidor 2 Cochera 3 Estudio 4 Baño 5 Comedor 6 Sala 7 Terraza 8 Cocina 9 Cto. de Serv. 10 Patio de Serv. 11 Cto. de Máquinas 12 Alberca 13 Recamara 1 14 Recámara 2 15 Estar TV 16 Recámara Principal
