This comprehensive architectural drawing set depicts a single-story residential bungalow with a total built-up area of 110.20 sqm on a 150 sqm plot. The floor plan features a functional layout with two bedrooms (3.65×4.35m and 3.65×3.10m), a living room (4.15×5.05m), kitchen (4.90×3.30m), bathroom (1.20×2.25m), toilet (1.05×1.20m), storage (2.85×1.20m), and front porch (2.40×5.20m). The drawing includes detailed plumbing components with a septic tank design, soakpit specifications, and an integrated rainwater harvesting system with filtration components. Construction details show RCC slab roofing (115mm thickness), brick masonry walls, and standard door/window schedules (main doors at 1.20×2.10m, windows at 1.80×1.20m). The documentation includes front elevation, site plan, sectional details, and all regulatory compliance information required for municipal approval, with a calculated carpet area of 84.16 sqm which represents 76.4% of the built-up area.
Single-Story Residential Bungalow Floor Plan with Rainwater Harvesting
