Large distribution center site plan, includes the main warehouse footprint and a massive maneuvering yard (~4,670 m²) with asphalt paving. I’ve detailed out the staff and visitor parking areas—153 spaces total—along with a 40x70m soccer field and green spaces. Technical areas like the fire pump house, cisterns, electrical cabin, and a selective waste area are all there. It also features a 285 m³ retention basin and specific access points for trucks & vehicles. Scale is 1:500. Solid reference for logistics hubs or manufqcturing site layouts. Text is in Portuguese.
Site layout for industrial distribution center with maneuvering yard
