Steel Roof Truss Reticulated DWG Detail for AutoCAD

Steel roof truss reticulated – Armed detail 24 m light

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Threaded at one end., Round steel straps, see, Tensioner angles, Uprights, Diagonal angles, Lower string angles, Top rope angles, axis

Raw text data extracted from CAD file:

(TIPO) 0=1.9 ROSCADO EN UN EXTREMO. TIRANTES DE ACERO REDONDO VER DET.-7 VER DET.-6 VER DET.-5 VER DET.-4 VER DET.-3 VER DET.-2 VER DET.-1 DE 5.1×5.1×0.5 TENSOR ANGULOS DE 5.1×5.1×0.5 MONTANTES ANGULOS DE 5.1×5.1×0.5 DIAGONALES ANGULOS CUERDA INFERIOR ANGULOS DE 7.6×7.6×0.6 DE 7.6×7.6×0.6 CUERDA SUPERIOR ANGULOS 15 A R M A D U R A. A – 1 EJE EJE 15 2400 225 37.7 145 145 145 145 145 145 145 145 145 145 145 145 145 145 145 145 37.7 50 60
