Soporte type swing swing type single-channel based on constructive losacero
Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):
Of engineering, Of project:, Engineering management, of the project, first name, specialty, date, key, Esc, Materials relationship, Nut with flat washer, Expansion, Threaded rod of up to length., Adjustable clamp type pear mod. Of diameter required., Sanitary installation pipe fire protection., Ariable, variable, Var., variable, Concrete slab type losacero, N.p.t., Concrete slab type losacero, Maximum distance between supports, external diameter, separation., For polypropylene pvc pipe random, Pipe projection, see detail, Support in type, hydraulics, February, Plant view, Esc, Front cut view, Esc, Side cut view, Esc, Isometric view, Esc., Isometric view, Esc., Notes: all installations will be executed with drill only. The use of explosive charges is prohibited. For the complete interpretation of the present, refer to the descriptive memo.
