Swimming Pool Construction Plan with Hydraulic Systems & Sections

This comprehensive swimming pool shop drawing illustrates a rectangular pool with complete hydraulic infrastructure. This drawing includes floor plans, foundation details, cross-sections (A-A and B-B), and plumbing system layouts. The pool measures 6000mm × 3000mm with a maximum depth of 1.4m and features a dry edge (‘BIBIR KERING’) up to 1m wide. Key hydraulic components include a dedicated pump room, balancing tank, and filtration system with clearly labeled pipe connections: skimmer pipes (1.5″), main drain pipes (1.5″), inlet fittings (1.5″), balance tank pipes (1.5″), fill pipes (1.5″), drain pipes (1.5″), water level pipes (1.5″), and 3″ overflow pipes. The drawing delineates two distinct plumbing systems (A and B) and illustrates how water circulates through the filtration system. The foundation plan shows the structural support system with columns and beams necessary to accommodate the pool’s weight and pressure. Critical design considerations include proper drainage paths, water level maintenance systems, and positioning of access points for maintenance. The comprehensive technical specifications ensure proper hydraulic flow while the balanced arrangement of inlet and outlet fittings promotes effective water circulation and filtration.
