Acoustic Insulation Details DWG Detail for AutoCAD

Detail Wall – Roof

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Meeting wall panel ceiling existing plaster. Elastic base. Snbs profile uprights mm. Panel of rock wool. Density rocdan sandwich acoustic. Gypsum plasterboards m.a.d. Security panel

Raw text data extracted from CAD file:

ENCUENTRO PARED MEDIANERA – TECHO 1. Soporte existente enlucido. 2. Base elástica. SNBS 3. Perfil montante 46/70 mm. 4. Panel de lana de roca. Densidad 70 kg/m 3 . ROCDAN 231/40 5. Sandwich acústico. 2 placas yeso laminar 13 + M.A.D. 4 6. Panel de seguridad.
