Archeological Complex 2D DWG Design Section for AutoCAD

This archeological complex is a residential plant for researchers, consisting of a one level building that has terrace, dining room, kitchen, bathrooms, bedrooms, and gardens. You can see the plans of electrical installation, the plans of sanitary installations, the plans of foundations, a lateral view and a frontal view

Language Spanish
Drawing Type Section
Category
Additional Screenshots


File Type dwg, zip
Materials Concrete, Steel, Wood
Measurement Units Metric
Footprint Area 500 - 999 m² (5382.0 - 10753.1 ft²)
Building Features Garden / Park
