Gas Details DWG Detail for AutoCAD

Gas Details DWG Detail for AutoCAD

Here you will find details of all types to make a map of this file contains gas from views to the elements for a 45 °, also on the ground all that are needed.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Esc., Lm, Conlind axis., Ventilation sup. Nag surface free of ventilation, Ventilation inf. Nag surface free of ventilation, Low epoxy, Epoxy, Go up epoxy, Low epoxy, Epoxy, Go up epoxy, Rigid connection, Installer: camacho oscar mat. Cat., Locality: san martín province mendoza, Gas installation, Street: pringles nº, Between: street carmen street perrupato, Owner’s signature, Plumbing detail, references, Location sketch, Installer’s signature, Perruato street, Carmen street, Street pringles, ventilation, Pipe exist., Kitchen ventilation ch. Galv., Capacity bar regulator, Capacity meter, total, Niche for natural gas, Boiler tbu. Ventilation ch. Galv., Arjonilla street, scale:, Ventilation inf. Nag surface free of ventilation, Cabinet detail, Apartment, Spherical, Regulatory detail, key, Regulators, key, Spherical, key, Spherical, key, Spherical, service, Plugged mouth

Raw text data extracted from CAD file:

ESC. 1:100 L.M Eje Conlind. Eje Conlind. Eje Conlind. 5 - VENTILACION SUP. NAG 215 SUPERFICIE LIBRE DE VENTILACIÓN 200mm 6 - VENTILACION INF. NAG 215 SUPERFICIE LIBRE DE VENTILACIÓN 200mm 1 Baja 0.90m Ø 1" Epoxi 4.90m Ø 1" Epoxi 9.85m Ø 1" Epoxi 0.60m Ø 1/2" Epoxi 1.40m Ø 3/4" Epoxi Sube 1.80m Ø 1/2" Epoxi Baja 0.60m Ø 1/2" Epoxi 0.60m Ø 3/4" Epoxi Sube 1.70m Ø 3/4" Epoxi Conexión Rígida de 1/2" Conexión Rígida de 3/4" INSTALADOR: CAMACHO , OSCAR MAT. 32108 CAT. 3ra. LOCALIDAD: SAN MARTÍN PROVINCIA : MENDOZA INSTALACION DE GAS CALLE: PRINGLES Nº 378 ENTRE: CALLE CARMEN y CALLE PERRUPATO FIRMA DEL PROPIETARIO DETALLE CAÑERIA REFERENCIAS CROQUIS DE UBICACION N FIRMA DEL INSTALADOR CALLE PERRUPATO CALLE CARMEN CALLE PRINGLES VENTILACION CAÑERIA EXIST. 2 - COCINA 10.000 c/h ( Ventilación Ch. Galv. ø 120) REGULADOR 4 BAR - CAPACIADAD 6 m ³ / h MEDIDOR CAPACIDAD m ³ / h TOTAL = 35.500 c / h 1 - NICHO PARA GAS NATURAL 3 - CALDERA TBU. 25.500 c/h ( Ventilación Ch. Galv. ø 75) CALLE ARJONILLA ESCALA: 1: 100 2 3 4 - VENTILACION INF. NAG 215 SUPERFICIE LIBRE DE VENTILACIÓN 100 cm2 3 2 1 5 DETALLE DE GABINETE d38mm d19mm d25mm d19mm d25mm d19mm DEPTO. 12 d25mm d19mm d25mm d19mm d25mm d19mm d25mm d32mm d38mm d25mm d19mm d25mm d19mm d25mm d19mm d19mm d19mm d19mm ESFERICA DETALLE DE REGULACION LLAVE 1" d63mm 50m3/h-C/U 2 REGULADORES LLAVE ESFERICA LLAVE ESFERICA d63mm LLAVE ESFERICA d63mm SERVICIO d63mm 1" 1" 1" Boca Taponada

Language	Spanish
Drawing Type	Detail
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features	Car Parking Lot
Tags	autocad, DETAIL, details, DWG, einrichtungen, elements, facilities, file, find, gas, gas details, gesundheit, ground, l'approvisionnement en eau, la sant, le gaz, machine room, map, maquinas, maschinenrauminstallations, provision, types, views, wasser bestimmung, water
