Grease Trap DWG Detail for AutoCAD

Specific detail grease trap water machine restaurant .

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Front of drainage, Macarone santa peten, Lateral drainage, Macarone santa peten, Duo strainer basket, Screw thread, Pvc tube, Male adapter, Inlet with internal thread set, Exit with nipple, Wait drainage main network

Raw text data extracted from CAD file:

0.25 0.12 0.37 0.05 0.44 0.03 0.51 0.25 0.12 0.37 0.53 0.36 0.19 0.1 1.5 1.6 0.23 0.35 0.55 1.12 0.94 0.51 0.44 0.1 0.18 0.5 0.52 \lSECCION FRONTAL DE DRENAJE \lESCALA: 1:10 \lAL MACARONE SANTA ELENA, PETEN \lSECCION LATERAL DE DRENAJE \lESCALA: 1:10 \lAL MACARONE SANTA ELENA, PETEN 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 canasta Duo Strainer Copla de rosca de 1 1/2″ Tubo de PVC Ø 1 1/2″ Adaptador macho Ø 1 1/2″ Entrada con copla de Ø 1 1/2″ rosca interna Salida con niple Ø 2″ Espera drenaje Ø 2″ a red principal 5 5 5 5
