North Facade Elevation for 4-Story Residential Building

North elevation CAD drawing of a 4-story building showing architectural level markers, window openings, and slab heights.

North elevation showing floor levels and slab heights for a multi-story building. Covers the roof deck, firewall, ground level & more.

FREE

File Details

File Type
DWG
Type
Elevation
Language
English
Materials
Concrete, Glass, Masonry
Units
Metric
Area
150 – 249 m² (1614.6 – 2680.2 ft²)
Features
Deck / Patio
Uploaded by
Studio DWG
Downloads
2 downloads
Category
Apartment, Residential
Published
Jun 1, 2026

Download faster, ad-free, with more daily files from $7/mo

Tags

apartment architecture building levels construction details elevation facade multi-story building north elevation roof deck slab soffit
