Comprehensive industrial piping components library featuring ASME B16.5 flanges and elbows in various pressure classes and configurations. The drawing includes detailed representations of WNRF (Weld Neck Raised Face), LWNRF (Long Weld Neck Raised Face), and SORF (Slip-On Raised Face) flanges in 150#, 300#, 400# and 600# pressure classes across pipe sizes from 15NB to 600NB. Also features 90° long radius and short radius ASME elbows scaled proportionally by diameter, standard couplings in 3000# class, and specialized vessel davit assemblies for both horizontal and vertical applications. Components conform to ASME standards with detailed dimensional accuracy for engineering applications in refinery and petrochemical projects. Notable design features include integrated blind flange configurations and properly scaled transition elements for system integration.
Piping Components Detail Library with ASME Flanges and Elbows
