A detailed architectural drawing set for a residential barbecue area (churrasqueira) renovation project. This main sheet shows a floor plan at 1:50 scale with kitchen fixtures including a sink (Pia cozinha) and a four-burner stove (4bocas). The drawing distinguishes between existing elements, structures to be demolished, and new construction with different layer treatments. Additional sheets include a 1:1000 situation plan showing the property’s location and context, plus construction details with sections and elevations. The project includes plumbing fixtures with drain installations and appears to be part of a Brazilian residential property modification from September 2021, as indicated by the process number 02/42/000462/2020 on the title block. The drawing adheres to local building codes with required professional responsibility statements for both the project designer and execution contractor.
Residential churrasqueira Floor Plan with Situation Plan
