Topographic Site Survey with Contour Lines and Spot Heights

Name: Topographic Site Survey with Contour Lines and Spot Heights
Brand: Designs CAD
SKU: 845048
Availability: InStock

Topographic survey plan showing elevation contour lines, spot heights, coordinate markers, and north arrow.

Detailed topographic site survey featuring spot heights and contour lines. Includes coordinate grids, north orientation and layers for specific materials like concrete & stone.

FREE

File Details

File Type: DWG
Type: Plan
Language: Other
Materials: Concrete, Masonry
Units: Metric
Area: 1000 – 2499 m² (10763.9 – 26899.0 ft²)
Features: Garden / Park
Uploaded by: Studio DWG
Category: Parks & Landscaping, Public Facilities
Published: May 30, 2026
