Two-Story Residential Structural Plan with footing and Column Details

Complete structural documentation for a two-story residential building in Isabela, Philippines, conforming to NSCP 2010 standards. The package includes foundation plan, floor framing plans, and comprehensive structural details:

Foundation System:
– Square isolated footings (F1: 1.2m×1.2m and F2: 1.0m×1.0m)
– 120mm thick slab-on-grade with 100mm compacted base course
– Tie beams (200mm×400mm) with 6-D16mm main reinforcement bars

Column System:
– Three column types (C1, C2, C3) with 200mm×400mm dimensions
– Primary reinforcement: Grade 60 steel (414 MPa)
– Lateral ties: Grade 40 steel (276 MPa)
– Seismic detailing per ACI standards

Beam System:
– Standard beam dimensions: 200mm×400mm
– Detailed splice requirements and joint reinforcement specifications
– Comprehensive beam schedule with reinforcement details

The structural design accounts for local seismic considerations with properly detailed connections between structural elements. Concrete strength requirements are specified at 21.0 MPa for footings and 27.6 MPa for columns and beams, with comprehensive reference tables for reinforcement development lengths and splicing requirements.
