Typical Catch Basin Detail with Heavy Duty Cover

Catch basin section for drainage, incl. a 300×300 C.I heavy duty cover & frame. It’s got the GRP perforated bucket, lifting handle, & 110mm outlet connections.Detalle de sumidero típico con tapa de hierro fundido y cesta perforada

FREE

File Details

File Type
DWG
Type
Detail
Language
English
Materials
Steel, Plastic, Concrete
Units
Metric
Area
1 – 9 m² (10.8 – 96.9 ft²)
Uploaded by
Eng_Plans
Downloads
1 downloads
Category
Public Facilities, Water Sewage & Electricity Infrastructure
