Apartment Building DWG Block for AutoCAD

APARTMENT BUILDING WITH HOME FRONT, GROUND FLOOR PARKING AND ARCHITECTURAL AND ALSO WITH BASEMENT. DESIGN DEPARTMENTS

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

elevator, up, access, cars, parking plant, main facade, blueprint, apartment building, north, bedroom, living room, kitchen, dining room, bathroom, hall, cupboard, low, service yard, light well , built surface, architectural plant, green area

Raw text data extracted from CAD file:

1 2 3 4 5 6 7 8 elevador sube acceso acceso autos planta de estacionamiento escala 1:100 fachada principal escala 1:100 ANTEPROYECTO EDIFICIO DE DEPARTAMENTOS NORTE recamara recamara elevador sube sala – comedor cocina sala comedor acceso recamara baño baño vestibulo alacena baja patio de serv. recamara recamara recamara sala comedor cocina cocina alacena alacena patio de serv. patio de serv. pozo de luz pozo de luz depto 1 acceso depto 3 acceso depto 2 superficie construída departamento 1 87.95 m2 departamento 2 90.68 m2 departamento 3 65.83 m2 baño baño baño superficie total de terreno 436.07 m2 superficie sin construir 165.94 m2 planta arquitectonica escala 1:100 area verde 11 12 13 14 15 16 17 18 elevador sube planta de estacionamiento escala 1:100 ( sótano ) 20 19 sube baja 21 10 9
