Balcony Detail DWG Detail for AutoCAD
Detail of balcony slabs prestressed
Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):
student: natalia, theme: a piece of furniture, t.p., ii u.p.b, date, of balcony esc:, union with special glue for blocks hºcca type retak, masonry mortar joints, self-drilling screw, molding of hºcca type retak, fine, masonry of elevation of common bricks of chacra, folded sheet profile, hexagonal head, self-drilling screw, plaster rock plates, beam of hºaº stirrups, aluminum hook, black wire candle, Hollow prestressed hollow slab, Glazed ceramic pedestal, glazed ceramic adhered with klaukol type adhesive, concrete bulldozer folder, concrete compression folder, filling of concrete board, hardwood railing type cedar treated with marine varnish bright resist. humidity, metal plate, transparent float type glass, bronze rivet, chº gº’s profile
Raw text data extracted from CAD file:
| Language | Spanish |
| Drawing Type | Detail |
| Category | Construction Details & Systems |
| Additional Screenshots |
 |
| File Type | dwg |
| Materials | Aluminum, Concrete, Glass, Masonry, Wood |
| Measurement Units | |
| Footprint Area | |
| Building Features | |
| Tags | autocad, balcony, block, brick walls, constructive details, DETAIL, DWG, mur de briques, panel, parede de tijolos, partition wall, prestressed, slabs, ziegelmauer |
