Structural details and finishes in elevation of a module of bathrooms in a building with slabs, beams and other important technical details.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Sanitary, mens., Galvadek metal structural slab., Double wall for ceramic veneer., false sky, Twist it., Main girder in elevation on axis, station, of coffee., Secondary beam., Electric duct, Hydraulic pipe, Npt, Wooden shelf detail of, Wooden plug detail of

Raw text data extracted from CAD file:

Pma-6 V-11 SANITARIOS HOMBRES. LOSA ESTRUCTURAL METALICA TIPO GALVADEK. LOSA ESTRUCTURAL METALICA TIPO GALVADEK. A1 1 A1 1 A1 1 DOBLE PARED PARA ENCHAPE DE CERAMICA. B1 4 CIELO FALSO B1 4 ENTRECIELO. ENTRECIELO. VIGA PRINCIPAL EN ELEVACION SOBRE EJE 7. ESTACION DE CAFE. VIGA SECUNDARIA. DUCTO ELECTRICO DE-1 (40x40cms.) DUCTO HIDRAULICO DH-1 (50x40cms.) TR 1 B1 1 B1 1 TR 1 TR 3 B1 4 NPT NPT Pma-6 Pma-6 REPISA DE MADERA (ver detalle de Pma-6) TAPON DE MADERA (ver detalle de Pma-6) V-11
