This drawing set details a built-in wardrobe installation for a mid-sized villa bedroom. The design features a full-height wardrobe system with both hanging storage and shelving compartments, standing approximately 2.6m tall. The cabinetry includes veneer finishes with detailed millwork specifications for carcass construction. The left section provides hanging space while the right portion incorporates a series of adjustable shelves. Hardware specifications include precision hinges for the swing doors and horizontal handles. The wardrobe integrates with the bedroom architecture through carefully detailed architraves and backing panels. The drawing includes both front elevations and sectional views showing the internal configuration, with particular attention to joinery details at wall junctions. Installation height references are provided relative to finished floor level (0.00+), with key dimensions provided in millimeters throughout. The design balances aesthetics with practical storage requirements, incorporating adequate depth (600mm) for clothing storage while maintaining accessibility.
Built-in Bedroom wardrobe Section and Elevation for Mid-Villa
