Architectural set for the Capilla de San Antonio, a small religious structure with a unique trapezoidal footprint. These 2D CAD drawings are presented at a 1:50 scale across five sheets, providing a complete basic design package.
The file includes a general floor plan (Planta General), a foundation plan (Plano Cimientos) with structural details, and a specific column detail. For vertical documentation, the set provides the main front elevation (Fachada Principal), a side elevation (Fachada Lateral), and a longitudinal section (Corte a-a’) showing interior heights and construction layers. Includes ground-level context and human figures for scale. Capilla de San Antonio, Distrito XI.
