Detail Water Drainage DWG Section for AutoCAD

Detail water drainage – Constructive section Floor to roof – Circle column in armed concrete

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Rustic aztec ceramic flooring, Mortar cement sand, Radier cm, Moisture barrier polyethylene sheet mm, Layer of cm sand, Cm gravel cover, Compacted ground, Concrete reinforced foundation, Laminated timber, Pine, Insulated asphalt pavement cover, Beam s, Oregon sky pine lining, Thermal insulation isopac mm, Diagonal enamel, Felt of, American sky, Radial armed hoist beam, Stucco grain lost, Cylindrical pillar reinforced concrete, Mocheta reinforced concrete ring, Reinforced concrete capital, Metal bolt, Pieces pine insigne reinforced water channel, Sealing concrete asphalt membrane heat-sealed, Rain channel receptacle in galvanized steel mm, Pine cone, detail

Raw text data extracted from CAD file:

Pavimento : Cerámica Azteca Rústica Mortero cemento y arena Radier 10 cm Barrera de Humedad : Lámina de Polietileno 0.3 mm Capa de Arena de 10 cm Capa de Ripio de 20 cm Terreno Compactado Fundación Hormigón Armado S/C VIGA Madera Laminada Coigüe 100 / 350 Costaneras Pino Insigne 2 ‘ x 3 ‘ Cubierta : Tejuela Asfáltica Gravillada VIGA Madera Laminada Coigüe Curva 75 / 150 Forro Cielo Pino Oregón 1 ‘ x 4 ‘ Aislante Térmico : ISOPAC 50 mm Encamizado Diagonal de Pino Insigne de 1 ‘ x 4 ‘ Fieltro de 12 l b s . Cielo Americano Viga Hoemigón Armado Radial Estuco a grano perdido Pilar Cilíndrico Hormigón Armado Mocheta Anillo de Hormigón Armado Capitel de Hormigón Armado Perno Metálico Piezas Pino Insigne ( armado de canal de agua ) Sellado hormigón : Membrana Asfáltica Termosoldada Receptáculo canal lluvia en Acero Galvanizado 0.5 mm Cuña de Pino Insigne DETALLE 4
