Elevation and Section XX views for a residential structure featuring a multi-tiered pitched roof. Includes typ. vertical clearances of 10′-0″ and 9′-0″, with a max ridge height of 15′-3″ above the first floor level. Drawing covers stair configuration, masonry wall sections, and internal spatial arrangements for a multi-level dwelling.
Elevation and Cross Section Views for a Two-Story Residence
