Restauranrt – Plants – Sections – Elevations
Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):
made by coconut, npt:, entrance hall awaits public, s.h. men, thematic patio, sidewalk, metal structure with wooden platform to support raised tank, stage with motives moche, court bb, living room, court cc, secondary accesses, demonstration modules, avenue albarracin, npt, entry service, service area, cooking area, preparation area, kitchen, dining room service, laundry area, bar, beverage tank, delivery area, projection of the aerial beam, hall reception, sh males, s.h. ladies, men’s dressing room, ladies dressing room, dry food storage, food and vegetable storage, cold room, stay, administration, green area, main entrance, wardrobe, cash desk, tables, expansion tables, mountain restaurant, planimetry, arq garcia, arapa puma christian, faculty of architecture and urbanism – unsa, subject, student, blueprints, scale, subject, chair, streetlamp lighting, children’s games, main elevation, later elevation, expansion of tables, cut to -a, cut bb, cuts elevations, plant restaurant
