Industrial Recycling Plant Layout with Rotary Sieve System

This drawing depicts a comprehensive layout for an aluminum recycling plant with particular focus on the rotary sieve material sorting system. The facility includes multiple processing areas, conveyor systems, and material handling equipment. The main rotary sieve system features a 12-meter drum with 22kW motor drive and multiple screening sections for sorting aluminum scrap into various size fractions (0-4mm, 4-8mm, 8-15mm, 15-24mm, and 24-35mm). The layout shows feeding conveyors (9.3m length, 800mm width) connecting to vibrating screens (3.0m x 1.0m) and secondary conveyors. The plant includes bag house dust collection systems (35,000 CMH capacity) with ductwork connections. Site infrastructure shows paved roads (4m wide), drainage systems with harvesting chambers, and appropriate material flows between processing areas. The document includes multiple revision iterations with progressive design refinements to optimize material handling efficiency and dust containment.
